Central Locking Caster-2D

  • 125mm 2D-2 Central Locking Single-Wheel Caster

125mm 2D-2 Central Locking Single-Wheel Caster

PRODUCT DESCRIPTION

Swivel caster with total lock, directional lock and free movement. Twin wheels with precision ball bearing and covers. Housing and wheel core made of Nylon-PA6. High load-bearing capacity TPE wheel tread assures of quiet and stable rolling.
Apply to the stem with cam hole.

Using TPU wheel surface, has excellent shock absorption, wear resistance,safe and reliable.


Metel skeleton structure, safe and reliable; precision ball bearing, rotating, scrolling smoothly; no noise; in the control system has a stable two or three function, with elegant appearance, easy replacement; to meet different needs.


Rolling smoothness

Mute level

Wear resistance

Anti-rust properties


Technical Data ℃/mm/Kg

. Wheel diameter

125

. Tread width

32

. Hardle-∮

28

. Hardie length

50

. Offset

60

. Turning diameter

320

. Total height

164

. Temperature


. Standard


. Weight

1.1kg

. Load capacity

125kg

. Load capacity (static)

150KG

. Hardness of thread

98A

. Installed with thread

M8*1.25
